td8570 testing apparatus for dc magnetic properties of yoke steel sheets

measure hm, bm, jm, br, hc, μ, μm. draw b-h or j-h loops, magnetization and permeability curves.

reference

- gb/t 3655-2008
- gb/t 3656-2008
- gb/t 13012-2008
- gb/t 13888-2009
- iec 60404-2
- iec 60404-4
- iec 60404-7

application

- uut: grain-oriented / non-oriented silicon steel, transformer, iron core.
- epstein frame method: generate 75 ka/m magnetic field with 700t epstein frame.
- measuring dc parameter: hm, bm, jm, br, hc, μi, μm .
- drawing magnetizing curve, hysteresis loop, permeability curve.
- measurement method: ballistic method and scanning method.

features

- tester is traceable, it can be calibrated by higher standard voltmeter / amperemeter / power meter.
- automatic demagnetization.
- equip with software for calculating, drawing curve, and data management.
- modular design for update and maintenance.

parameter of magnetic measurement

parameter of electrical measurement

automatic software

5.1

5.2

5.3

5.4
