td1365 precision i/v converter -必赢亚赢

overview

model td1365, a precision ac and dc i/v converter. the optimal accuracy class is up to 0.005, the nominal output voltage is 1 v.

combine with data collectors to analyze harmonics, and to measure ratio difference, phase angle difference. combine with v-v dividers to build measurement system of voltage, current, power, frequency, phase and power factor.

features

● current measurement capability: 10 a to 600 a, range switching by automatic or manual. not easy to damage when overloaded.

● current conversion modes: dc, ac and dc+ac, 3 modes can be switched freely.

● dc measurement mode: 7 digits display with an accuracy of class 0.005.

● ac measurement mode: 6 digits display with an accuracy of class 0.01 at a frequency from 5 hz to 1 khz.

● excellent human-computer interaction: large lcd touch screen, more intuitive of value display and easier operation.

electrical specifications

measurement characteristics

● range switching: automatic or manual

● measuring range: 10 a to 600 a

● display: 7 digits for dc, 6 digits for ac.

● frequency: 5 hz to 1 khz

general specifications

● line power: 220 v ±22 v, 50 hz ±2 hz

● maximum power consumption: 60 va

● operating environment: 15 °c to +35 °c, 20 % to 85 % r·h, non-condensing

● storage environment: 0 °c to +40 °c, <95 % r·h, non-condensing

● dimensions (w × h × d): 400 mm × 205 mm × 195 mm

● weight: 8 kg
