overview

td3600 is a set of apparatus specially applied to the verification of three-phase meters. it is composed of standard three-phase ac power source, reference meter, multi-station verification workbench (built-in meter hanger, terminal knob, pulse input and output module, control module, display module, communication interface, anti-static table, etc) ,computer, proprietary software and so on. the accuracy is 0.01/0.02/0.05/0.1 optional, and reference standards are jjg 307-2006、jjg 596-2012、jjg 597-2005.

the apparatus is based on the stable output of three-phase ac power source. standard reference meter (td3300 or td3310) independently developed by tianheng is adopted as the accuracy assurance. combined with proprietary software, it can simultaneously have verification on 3-16 three-phase meters with the same voltage and current range, different constant and different error limit. the items include basic error test, start-up test, latent test, meter constant, daily timing error, time interval switching and so on.

features

● the minimum ac current output to 1 ma(0.1ma optional), which is the basis for start-up test of the verified meter.

● the apparatus has positive and reverse active electrical energy, four quadrant reactive power and other metering methods.

● multi-station verification workbench: simultaneous automatic verification of 3-16 three-phase meters is supported. the verification workbench is equipped with ac voltage / current output terminals, photoelectric pulse and communication interface to meet various kinds of testing requirements. and the control panel is built in so the operator can observe and control the output value by its lcd touch screen, which facilitates manual verification.

● proprietary software: semi-automatic and full-automatic verification is supported, so as data management and certificate export.

● harmonic function (options): it can load 2^nd-21^st harmonic with adjustable amplitude and phase to complete the harmonic influence test.

● crimping module (option): it is equipped with crimping module which makes no necessity for manual wiring and is convenient for users to complete the verification work.

technical specifications

 ac voltage output

output characteristics：

● range: 0 v～264v

● resolution: 0.002%*rg

● burden capacity: 15 va for each station

● display: 6 digits

● protection: short-circuit protection, overload protection

ac current output

output characteristics：

● range: 1 ma～120 a (0.1 ma optional )

● resolution: 0.002%*rg，

● burden capacity: 25 va for each station

● display: 6 digits

● protection: open-circuit protection, overload protection

frequency, phase and harmonic

● range of frequency: 45.000 hz～65.000 hz

   resolution: 0.001 hz

   accuracy: ± 0.01 hz

● range of phase: 0.000°～359.999°

   resolution: 0.005°

   accuracy: ± 0.05°

● symmetry of three-phase parameter: voltage≤+ 0.2%; current≤+ 0.5%; phase≤+ 0.5°

● harmonic output(option): 2^nd to 21^st，amplitude 0～40%、phase 0.0°～359.9° adjustable

stability of output power

accuracy of reference meter

measurement characteristics：

● ac power range: combination of ac voltage range and current range

● output of standard electrical energy pulse (high frequency): full scale value corresponds to 60 khz.

   output of standard electrical energy pulse(low frequency): full scale value corresponds to 6 hz.

   frequency jitter of output pulse: < 10 μs

● input of standard electrical energy pulse: high frequency pulse less than or equal to 150khz with the amplitude of 3.3v~24v can be received.

● the electrical energy error is automatically displayed with the resolution of 0.0001%.

general specifications

● line power: ac ( 220 ± 22 ) v，( 50 ± 2 ) hz

● operating environment: 0 ℃～40 ℃,20%～80% r·h, non-condensing

● storage environment: -20 ℃～70 ℃, < 80% r·h, non-condensing

● dimensions（width*depth*height）: 2800 mm × 750 mm × 1500 mm ( 6 stations workbench )

● standard interface: rs232
