td8650 tesla meter
- td8650 is a multifunctional magnetic field measuring instrument.
- it can be used as a basic magnetic parameter measuring instrument in magnetic material manufacturers and application units, machinery manufacturing enterprises, university research units, etc.
- the magnetic field
measurement is up to 3600 mt (36 kg) with 0.5% accuracy.
- dc measurement mode:
suitable for measuring the magnetic flux density of a constant magnetic field
or permanent magnet.
- ac measurement mode (optional):
suitable for measuring spatial alternating magnetic fields during 1 hz～400
hz.
- magnetic field polarity display: determine the n / s polarity by " /-".
- one-button unit switching:
mt or g, 1 mt = 10 g.
- one-button clear function:
to eliminate the influence of zero drift on the measurement.
- maximum value retention.
- over-limit warning function.
- standard rs232 interface for
setting up automatic testing system with computer.
- small size, light weight and
low power consumption, easy to carry.
- radial hall probe is standard,
axial probe is optional for different applications.
- zero drift calibration
(optional): equipped with a dedicated magnetic shielding cavity to calibrate
the zero drift of the instrument.
