td8900 fluxmeter
- td8900 is a high-precision flux measuring instrument that measures the magnetic flux of a space magnetic field or permanent magnet with types of coils.
- it can be widely used in the research and analysis of permanent magnets, soft magnetic materials or the quality control and screening of parts and components of motor transformers.
- wide measuring range: 0～2wb,
0.5% accuracy.
- one button zero drift
adjustment.
- one-click zero.
- flux unit switching: wb, mwb,
vs, mvs, etc.
- maximum maintenance.
- overrun alarm.
- by setting parameters such
as coil area and turns, the magnetic flux can be calculated automatically and
the unit t or g can be switched.
- high-definition lcd display, five-digit display, minimum resolution as low as 0.1 μwb.
- conventional flux coil:
suitable for measuring the flux of a single sample.
- skateboard coil: suitable
for testing batch samples on the production line.
- helmholtz coil: the magnetic
moment for the sample.
- stator coil: suitable for
measuring the magnetic flux of the stator core quickly.
- remarks: the above coils are optional and can be customized according to samples.
